S SERIES BUILDING-LIKE SAND-MAKER
Product Display
PRODUCT DATA
Technical Data of SSL Series Building-like Sand-maker
| Model | SSL60 | SSL100 | SSL150 | SSL200 | SSL450 |
| Feeding Size | ≤40mm | ||||
| Water Content of Raw Material | ≤3% | ||||
| Mud Content of Raw Material | ≤1% | ||||
| Type | Non-weathered soft and hard rocks | ||||
| Maximum Sand-making Capacity | 40-60TPH | 60-100TPH | 100-150TPH | 150-200TPH | 300-450TPH |
| Micro-fines Content in Sand | 5-15% Adjustable | ||||
| Content of Needle-like Particles | ≤8% | ||||
| Dust Control | Emissions of atmospheric pollutants are lower than GB16279 "Air Pollutant Release Standard" | ||||
| Maximum Sand-making Capacity | ~317kw | ~600kw | ~1260kw | ~1464kw | ~3630kw |
| Overall Dimension of Main Building | 20.2mx7.7mx17.8m | 11mx17mx30.2m | 22mx34mx30m | ||
Technical Data of SGL series building-like sand-and-gravel maker
| Model | SGL150 | SGL250 | SGL350 | SGL500 |
| Feeding Size | ≤40mm | |||
| Water Content of Raw Material | ≤3% | |||
| Mud Content of Raw Material | ≤1% | |||
| Type | Non-weathered soft and hard rocks | |||
| Maximum Sand-making Capacity | 40-60TPH | 60-100TPH | 100-150TPH | 150-200TPH |
| Maximum Gravel Capacity | 60-90TPH | 100-150TPH | 150-200TPH | 200-300TPH |
| Micro-fines Content in Sand | 5-15% Adjustable | |||
| Content of Needle-like Particles | ≤8% | |||
| Dust Control | Emissions of atmospheric pollutants are lower than GB16279 "Air Pollutant Release Standard" | |||
| Maximum Sand-making Capacity | ~360kw | ~600kw | ~1260kw | ~1464kw |
| Overall Dimension of Main Building | 20.2mx7.7mx17.8m | 11mx17mx30.2m | ||
FEATURES AND BENEFITS OF SSL, SGL SERIES BUILDING-LIKE SAND-MAKER
• Wide applications and multi-function
• It can process construction waste, stone debris, mine waste.
• High Production Capacity and High Quality
• The maximum input of building-like sand-and-gravel maker is 500t/h. The maximum feeding volume of building-like sand-maker is 200t/h.
• Intellectual control and safe production
• Simple Maintenance
• Wide range of water and mud content adaptability of raw materials
• Water and mud content≤10%.(Adding special water and mud removal system)
